RAVENOL ATF THS Truck HD Synthetic is a very high-quality synthetic transmission fluid with special additives and is particularly suitable for Allison automatic transmissions.
Հաստատված է արտադրողը:
Allison TES-668
Պահանջներին համապատասխանելը:
Allison TES-295, Allison TES-389, Allison TES-468, Caterpillar TO-2, DTFR 13C190 (MB 236.92), MAN 339 Type V1, MAN 339 Type V2, MAN 339 Type Z1, MAN 339 Type Z2, MAN 339 Type Z3, MAN 339 Z12, MB 236.7, MB 236.9, MB 236.92, Voith H55.63353x (G607), Voith H55.63363x (G1363), Volvo 97341, ZF TE-ML 04D, ZF TE-ML 05L, ZF TE-ML 14A, ZF TE-ML 14B, ZF TE-ML 14C, ZF TE-ML 16M, ZF TE-ML 16S, ZF TE-ML 20C, ZF TE-ML 21L, ZF TE-ML 25C
- Առկա փաթեթավորում
- Ապրանքի պարամետրեր
Ծավալը:
20 լ
վաճառողի կոդը:
1211151-020
Ծավալը:
60 լ
վաճառողի կոդը:
1211151-060
Ծավալը:
20 լ, ecobox
վաճառողի կոդը:
1211151-B20
RAVENOL ATF THS Truck HD Synthetic is a very high-quality synthetic transmission fluid with special additives and is particularly suitable for Allison automatic transmissions.
RAVENOL ATF THS Truck HD Synthetic was developed for year-round use under the toughest conditions and meets the requirements of many automatic transmissions in commercial vehicles and busses.
RAVENOL ATF THS Truck HD Synthetic improves friction and wear and leads to reduced noise and a smoother shifting process.
Application Note
RAVENOL ATF THS Truck HD Synthetic was developed for use in transmissions installed in commercial vehicles, especially for use in Allison truck and bus automatic transmissions.
RAVENOL ATF THS Truck HD Synthetic is particularly suitable if the specifications TES 668, TES 468, TES 389 or TES 295 are recommended.
RAVENOL ATF THS Truck HD Synthetic is to be used in accordance with the manufacturer's instructions.
Characteristics
- Very good friction resistance
- Excellent low temperature properties
- A thermally extraordinarily high load capacity
- Neutral behavior towards sealing materials
- Oxidation stable
- High shear stability
- Low maintenance costs due to extended oil change intervals
- Prevents deposits on transmissions
RAVENOL special transmission fluids are special developments for special gears and cannot be selected on the basis of technical parameters (viscosity, etc.). Therefore the decision was made not to give technical data. Please note: RAVENOL special transmission fluid is exclusively to apply under the original number, as indicated in the product information. If you are unsure about the right transmission fluid, ask your workshop or dealership for advice on the transmission type and OEM original number or ask our experts, making sure to state the VIN code (vehicle identification number) of your vehicle. Misapplication of RAVENOL special transmission fluid can lead to malfunction of the transmission shifting problems, increased fuel consumption, unwanted slip behavior, etc. and cause the failure of the transmission. Ravensberger Schmierstoffvertrieb GmbH is not liable for transmission failures in case of wrong selection of RAVENOL special transmission fluid.
| Կարգավորում | Չափման միավոր | Արժեք | Փորձարկում | |
|---|---|---|---|---|
| JASO | M315 Type 1A |
M315 Type 1A
|
||
| Brand | RAVENOL |
RAVENOL
|
||
| Տեսակ | Synthetic |
Synthetic
|
||
| Հաստատված է արտադրողի կողմից | Allison TES-668 |
Allison TES-668
|
||
| Համապատասխանում է արտադրողի պահանջներին | Allison TES-295, Allison TES-389, Allison TES-468, Caterpillar TO-2, DTFR 13C190 (MB 236.92), MAN 339 Type V1, MAN 339 Type V2, MAN 339 Type Z1, MAN 339 Type Z2, MAN 339 Type Z3, MAN 339 Z12, MB 236.7, MB 236.9, MB 236.92, Voith H55.63353x (G607), Voith H55.63363x (G1363), Volvo 97340, Volvo 97341, ZF TE-ML 04D, ZF TE-ML 05L, ZF TE-ML 14A, ZF TE-ML 14B, ZF TE-ML 14C, ZF TE-ML 16M, ZF TE-ML 16S, ZF TE-ML 20C, ZF TE-ML 21L, ZF TE-ML 25C |
Allison TES-295, Allison TES-389, Allison TES-468, Caterpillar TO-2, DTFR 13C190 (MB 236.92), MAN 339 Type V1, MAN 339 Type V2, MAN 339 Type Z1, MAN 339 Type Z2, MAN 339 Type Z3, MAN 339 Z12, MB 236.7, MB 236.9, MB 236.92, Voith H55.63353x (G607), Voith H55.63363x (G1363), Volvo 97340, Volvo 97341, ZF TE-ML 04D, ZF TE-ML 05L, ZF TE-ML 14A, ZF TE-ML 14B, ZF TE-ML 14C, ZF TE-ML 16M, ZF TE-ML 16S, ZF TE-ML 20C, ZF TE-ML 21L, ZF TE-ML 25C
|
||
| Համապատասխանում է արտադրողի բնութագրերին | GM Dexron® II D, GM Dexron® III G, GM Dexron® III H |
GM Dexron® II D, GM Dexron® III G, GM Dexron® III H
|
||
| Համապատասխանում է ապրանքներին | Ford XT-2-QDX, Motorcraft XT-5-QMC |
Ford XT-2-QDX, Motorcraft XT-5-QMC
|
||
| Հատուկ հզորություն 20°C-ի դեպքում | գ/սմ³ | 843 | EN ISO 12185 |
843
գ/սմ³
EN ISO 12185
|
| Գույն | Red | տեսողական |
Red
տեսողական
|
|
| Մածուցիկություն 100 °C-ում | mm²/s | 7 | DIN 51562-1 |
7
mm²/s
DIN 51562-1
|
| Մածուցիկություն 40 °C-ում | mm²/s | 34.5 | DIN 51562-1 |
34.5
mm²/s
DIN 51562-1
|
| Տեսականություն -40°C-ի դեպքում | մՊա*վրկ | 10.3 | ASTM D2983 |
10.3
մՊա*վրկ
ASTM D2983
|
| Մածուցիկության ինդեքս VI | 173 | DIN ISO 2909 |
173
DIN ISO 2909
|
|
| Բյուրեղացման ջերմաստիճան | °C | -45 | DIN ISO 3016 |
-45
°C
DIN ISO 3016
|
| Կառուցման ջերմաստիճան | °C | 228 | DIN EN ISO 2592 |
228
°C
DIN EN ISO 2592
|
| Թույլատվություններ | Allison TES-295, Allison TES-389, Allison TES-468, Allison TES-668, Caterpillar TO-2, DTFR 13C190 (MB 236.92), GM Dexron® II D, GM Dexron® III G, GM Dexron® III H, MAN 339 Type V1, MAN 339 Type V2, MAN 339 Type Z1, MAN 339 Type Z2, MAN 339 Type Z3, MAN 339 Z12, MB 236.7, MB 236.9, MB 236.92, Voith H55.63353x (G607), Voith H55.63363x (G1363), Volvo 97340, Volvo 97341, ZF TE-ML 04D, ZF TE-ML 05L, ZF TE-ML 14A, ZF TE-ML 14B, ZF TE-ML 14C, ZF TE-ML 16M, ZF TE-ML 16S, ZF TE-ML 20C, ZF TE-ML 21L, ZF TE-ML 25C |
Allison TES-295, Allison TES-389, Allison TES-468, Allison TES-668, Caterpillar TO-2, DTFR 13C190 (MB 236.92), GM Dexron® II D, GM Dexron® III G, GM Dexron® III H, MAN 339 Type V1, MAN 339 Type V2, MAN 339 Type Z1, MAN 339 Type Z2, MAN 339 Type Z3, MAN 339 Z12, MB 236.7, MB 236.9, MB 236.92, Voith H55.63353x (G607), Voith H55.63363x (G1363), Volvo 97340, Volvo 97341, ZF TE-ML 04D, ZF TE-ML 05L, ZF TE-ML 14A, ZF TE-ML 14B, ZF TE-ML 14C, ZF TE-ML 16M, ZF TE-ML 16S, ZF TE-ML 20C, ZF TE-ML 21L, ZF TE-ML 25C
|
||
| Ֆոսֆորի պարունակությունը | mg/kg | 2,1 | ASTM D5800 |
2,1
mg/kg
ASTM D5800
|
RAVENOL ATF ZMS was developed with a high-quality synthetic base oil and a special selection of additives and inhibitors to produce excellent thermal and oxidation stability and adhesion factor performance. This guarantees the perfect functioning of the automatic transmission.
Պահանջներին համապատասխանելը:
MAN 339 Type Z3, MAN 339 Type Z4, ZF TE-ML 04D, ZF TE-ML 14E, ZF TE-ML 16N, ZF TE-ML 16Q, ZF TE-ML 20F
Անալոգներ OEM:
MAN 09110030517, ZF 0671072120, ZF 0671072130, ZF 0671072140, ZF 0671072180, ZF 0671072180, ZF 0671700270, ZF 0671700280
- Առկա փաթեթավորում
- Ապրանքի պարամետրեր
Ծավալը:
1 լ
վաճառողի կոդը:
1211102-001
Ծավալը:
4 լ
վաճառողի կոդը:
1211102-004
Ծավալը:
10 լ
վաճառողի կոդը:
1211102-010
Ծավալը:
20 լ, ecobox
վաճառողի կոդը:
1211102-B20
Ծավալը:
60 լ
վաճառողի կոդը:
1211102-060
Ծավալը:
208 լ
վաճառողի կոդը:
1211102-208
Ծավալը:
1 000 լ
վաճառողի կոդը:
1211102-700
RAVENOL ATF ZMS was developed with a high-quality synthetic base oil and a special selection of additives and inhibitors to produce excellent thermal and oxidation stability and adhesion factor performance. This guarantees the perfect functioning of the automatic transmission.
RAVENOL ATF ZMS demonstrates excellent flow properties at low temperatures.
RAVENOL ATF ZMS is a new generation ATF (Automatic-Transmission-Fluid) for ZF automatic transmissions of commercial vehicles. Guarantees maximum wear protection in every operating status.
RAVENOL ATF ZMS supports oil-change intervals up to 150,000 km, or a maximum of up to 3 years.
RAVENOL ATF ZMS enhances the reliability of older ZF transmissions, counters vibrations, ensures particularly soft gear changes as well as good driving comfort and also possesses friction-reducing properties.
RAVENOL ATF ZMS can contribute towards optimizing your servicing and operating costs by extending oil-change intervals. It is particularly recommended for applications with oil sump temperatures from 80°C up to 110°C according to ZF specification.
Application Note
RAVENOL ATF ZM was specially developed for heavy-duty ZF automatic transmissions used in local and regional public transport systems. Extreme loads, such as e.g. demanding topography, stop-and-go traffic and frequent retarder operation are not a problem for RAVENOL ATF ZM.
RAVENOL ATF ZM can be mixed with all ATF types of the ZF lubricant list TE-ML 04D. Oil and filter change intervals for Ecomat transmissions in busses up to 150,000 km, or every 3 years. Oil and filter change intervals for Ecomat transmissions in trucks, construction machinery and special vehicles during normal use (fire engines, construction vehicles and dumpers with high driving distances) after 2000 h or every 2 years.
Oil and filter change intervals under demanding conditions (refuse collection vehicles, vehicles with high off-road times (low distance, high gear shift rate) after 1500 h or once a year.
Characteristics
- Very good lubricant properties, even in low winter temperatures
- High, stable viscosity index
- Very good oxidation stability
- Excellent protection against wear, corrosion and frothing
- Excellent friction coefficient consistency
- High thermal and oxidative stability
- Excellent cooling properties
RAVENOL special transmission fluids are special developments for special gears and cannot be selected on the basis of technical parameters (viscosity, etc.). Therefore the decision was made not to give technical data. Please note: RAVENOL special transmission fluid is exclusively to apply under the original number, as indicated in the product information. If you are unsure about the right transmission fluid, ask your workshop or dealership for advice on the transmission type and OEM original number or ask our experts, making sure to state the VIN code (vehicle identification number) of your vehicle. Misapplication of RAVENOL special transmission fluid can lead to malfunction of the transmission shifting problems, increased fuel consumption, unwanted slip behavior, etc. and cause the failure of the transmission. Ravensberger Schmierstoffvertrieb GmbH is not liable for transmission failures in case of wrong selection of RAVENOL special transmission fluid.
| Կարգավորում | Չափման միավոր | Արժեք | Փորձարկում | |
|---|---|---|---|---|
| Brand | RAVENOL |
RAVENOL
|
||
| Տեսակ | Synthetic |
Synthetic
|
||
| Համապատասխանում է արտադրողի պահանջներին | MAN 339 Type Z3, MAN 339 Type Z4, ZF TE-ML 04D, ZF TE-ML 14E, ZF TE-ML 16N, ZF TE-ML 16Q, ZF TE-ML 20F |
MAN 339 Type Z3, MAN 339 Type Z4, ZF TE-ML 04D, ZF TE-ML 14E, ZF TE-ML 16N, ZF TE-ML 16Q, ZF TE-ML 20F
|
||
| Համապատասխանում է ապրանքներին | ZF 0671 072 120, ZF 0671 072 130 |
ZF 0671 072 120, ZF 0671 072 130
|
||
| Հատուկ հզորություն 20°C-ի դեպքում | գ/սմ³ | 843 | EN ISO 12185 |
843
գ/սմ³
EN ISO 12185
|
| Գույն | Blue | տեսողական |
Blue
տեսողական
|
|
| Բյուրեղացման ջերմաստիճան | °C | -51 | DIN ISO 3016 |
-51
°C
DIN ISO 3016
|
| Թույլատվություններ | MAN 339 Type Z3, MAN 339 Type Z4, ZF TE-ML 04D, ZF TE-ML 14E, ZF TE-ML 16N, ZF TE-ML 16Q, ZF TE-ML 20F |
MAN 339 Type Z3, MAN 339 Type Z4, ZF TE-ML 04D, ZF TE-ML 14E, ZF TE-ML 16N, ZF TE-ML 16Q, ZF TE-ML 20F
|
